Molding head parameters

Size (L): 250 - 2000mm

Material: Special steel, integral coating

Adjustment method: Upper dry caliper, lower differential bolt / push-pull rod adjustment

Accuracy (Straightness / Planeness)

a) 1000mm, ≤ 2μm, surface roughness Ras ≤ 0.025μm

b) 1000 - 2000mm, ≤ 3μm, surface roughness Ra ≤ 0.025μm

Coating width: 100 - 1850 mm

Mold cavity: Single/Liquid cavity (upper/lower layers)

Applicable range of slurry viscosity: 2000 - 25000 cps
