Molding head parameters

Size (L): 150 - 2000mm

Material: Special steel

Adjustment method: Subordinate and superior differential bolts adjustment

Accuracy (Straightness / Planeness)

a) 1000mm, ≤ 2μm, surface roughness Ra ≤ 0.025μm

b) 1000 - 2000mm, ≤ 3μm, surface roughness Ra ≤ 0.025μm

Coating width: 80 - 1900 mm

Mold cavity: Single/Liquid cavity

Applicable range of paste viscosity: 2000 - 25000 cps

Features: The adjustment mechanism is simple in design, the type change is easy, the cost is low, and the coating thickness stability is good.
